1/2" Electric Power Fittings HDG Forged Double Armign Bolts

Brand Name : LKY

Model Number : Double Armign Bolts

Certification : CE, ISO

Place of Origin : CHINA

MOQ : 1 ton

Price : Negotiable

Payment Terms : T/T

Supply Ability : 200 tons per month

Delivery Time : 60 days

Packaging Details : Carton + Pallet

Product Name : H.D.G. Forged Double Armign Bolts

Material : Carbon steel

Process : Hot forged

Surface : H. D. G.

Usage : Electric power fitting

Packing : Cartong + Pallet

Contact Now

H.D.G. Forged Double Armign Bolts

Double arming bolt is also called double threaded bolt, double ended bolt, or DA bolt. According to the length of the thread, the double arming bolts include all thread bolts and double threaded bolts. Contact us for size not listed on tables below.

1/2" DOUBLE ARMING BOLT WITH 2 NUTS

Length (Inches)	Finish	couple with	Weight
8	Hot Dip Galvanized	4 Square Nuts	0.61
10	Hot Dip Galvanized	4 Square Nuts	0.7
12	Hot Dip Galvanized	4 Square Nuts	0.79
14	Hot Dip Galvanized	4 Square Nuts	0.88
16	Hot Dip Galvanized	4 Square Nuts	0.97
18	Hot Dip Galvanized	4 Square Nuts	1.06
20	Hot Dip Galvanized	4 Square Nuts	1.15
22	Hot Dip Galvanized	4 Square Nuts	1.24
24	Hot Dip Galvanized	4 Square Nuts	1.33
26	Hot Dip Galvanized	4 Square Nuts	1.42
28	Hot Dip Galvanized	4 Square Nuts	1.51
30	Hot Dip Galvanized	4 Square Nuts	1.6
32	Hot Dip Galvanized	4 Square Nuts	1.69
34	Hot Dip Galvanized	4 Square Nuts	1.78
36	Hot Dip Galvanized	4 Square Nuts	1.87

5/8" DOUBLE ARMING BOLT WITH 4 NUTS

Length (Inches)	Finish	couple with	Weight
8	Hot Dip Galvanized	4 Square Nuts	0.95
10	Hot Dip Galvanized	4 Square Nuts	1.09
12	Hot Dip Galvanized	4 Square Nuts	1.23
14	Hot Dip Galvanized	4 Square Nuts	1.37
16	Hot Dip Galvanized	4 Square Nuts	1.51
18	Hot Dip Galvanized	4 Square Nuts	1.65
20	Hot Dip Galvanized	4 Square Nuts	1.79
22	Hot Dip Galvanized	4 Square Nuts	1.93
24	Hot Dip Galvanized	4 Square Nuts	2.07
26	Hot Dip Galvanized	4 Square Nuts	2.21
28	Hot Dip Galvanized	4 Square Nuts	2.35
30	Hot Dip Galvanized	4 Square Nuts	2.49
32	Hot Dip Galvanized	4 Square Nuts	2.63
34	Hot Dip Galvanized	4 Square Nuts	2.77
36	Hot Dip Galvanized	4 Square Nuts	2.91

3/4" DOUBLE ARMING BOLT WITH 4 NUTS

Length (Inches)	Finish	couple with	Weight
8	Hot Dip Galvanized	4 Square Nuts	1.43
10	Hot Dip Galvanized	4 Square Nuts	1.64
12	Hot Dip Galvanized	4 Square Nuts	1.85
14	Hot Dip Galvanized	4 Square Nuts	2.06
16	Hot Dip Galvanized	4 Square Nuts	2.27
18	Hot Dip Galvanized	4 Square Nuts	2.48
20	Hot Dip Galvanized	4 Square Nuts	2.69
22	Hot Dip Galvanized	4 Square Nuts	2.9
24	Hot Dip Galvanized	4 Square Nuts	3.11
26	Hot Dip Galvanized	4 Square Nuts	3.32
28	Hot Dip Galvanized	4 Square Nuts	3.53
30	Hot Dip Galvanized	4 Square Nuts	3.74
32	Hot Dip Galvanized	4 Square Nuts	3.95
34	Hot Dip Galvanized	4 Square Nuts	4.16
36	Hot Dip Galvanized	4 Square Nuts	4.37

7/8" DOUBLE ARMING BOLT WITH 4 NUTS

Length (Inches)	Finish	couple with	Weight
8	Hot Dip Galvanized	4 Square Nuts	2.04
10	Hot Dip Galvanized	4 Square Nuts	2.32
12	Hot Dip Galvanized	4 Square Nuts	2.6
14	Hot Dip Galvanized	4 Square Nuts	2.88
16	Hot Dip Galvanized	4 Square Nuts	3.16
18	Hot Dip Galvanized	4 Square Nuts	3.44
20	Hot Dip Galvanized	4 Square Nuts	3.72
22	Hot Dip Galvanized	4 Square Nuts	4
24	Hot Dip Galvanized	4 Square Nuts	4.28
26	Hot Dip Galvanized	4 Square Nuts	4.56
28	Hot Dip Galvanized	4 Square Nuts	4.84
30	Hot Dip Galvanized	4 Square Nuts	5.12
32	Hot Dip Galvanized	4 Square Nuts	5.4
34	Hot Dip Galvanized	4 Square Nuts	5.68
36	Hot Dip Galvanized	4 Square Nuts	5.96

1" DOUBLE ARMING BOLT WITH 4 NUTS

Length (Inches)	Finish	couple with	Weight
8	Hot Dip Galvanized	4 Square Nuts	2.69
10	Hot Dip Galvanized	4 Square Nuts	3.07
12	Hot Dip Galvanized	4 Square Nuts	3.45
14	Hot Dip Galvanized	4 Square Nuts	3.83
16	Hot Dip Galvanized	4 Square Nuts	4.21
18	Hot Dip Galvanized	4 Square Nuts	4.59
20	Hot Dip Galvanized	4 Square Nuts	4.97
22	Hot Dip Galvanized	4 Square Nuts	5.35
24	Hot Dip Galvanized	4 Square Nuts	5.73
26	Hot Dip Galvanized	4 Square Nuts	6.11
28	Hot Dip Galvanized	4 Square Nuts	6.49
30	Hot Dip Galvanized	4 Square Nuts	6.87
32	Hot Dip Galvanized	4 Square Nuts	7.25
34	Hot Dip Galvanized	4 Square Nuts	7.63
36	Hot Dip Galvanized	4 Square Nuts	8.01

1/2" Electric Power Fittings HDG Forged Double Armign Bolts

Packing & Delivery

1/2" Electric Power Fittings HDG Forged Double Armign Bolts

Product Tags:

1/2" Electric Power Fittings

Electric Power Fittings CE

HDG Forged double arming bolts
